C-65100 : SILICON BRONZE INGOTS

Description :

Silicon Bronzes are copper based alloys with a mixture of other metals like Aluminium, Nickel, Zinc, Lead, Iron and Manganese. It is one of the easiest metals to form/pour. Silicon helps deoxygenate the material which helps to reduce brittleness and increases the strength. Silicon has self-lubricating properties which makes it an ideal choice for connections or fixtures. Silicon Bronzes are less brittle than other bronze alloys. It is also considered as one of the best looking copper alloys due to its attractive reddish gold colour.

C65100 is known as Low Silicon Bronze which is one of the most weldable copper alloys. C65100 is noted for its strength, corrosion resistance, electrical properties and brazeability.

CHEMICAL COMPOSITION :

ELEMENT	Copper	Iron	Manganese	Zinc	Lead	Silicon
Min (%)	Balance	-	-	-	-	0.80
Max (%)	Balance	0.80	0.70	1.50	0.05	2.00

Note: Ni includes Co; Cu+ named elements >= 99.5%; Unless otherwise noted, single values represent maximums.

AEPL produces CuSiMn1, C64200, C65500, C87300, C95600, Silicon Bronze Ingots alloy in the form of Certified Ingots weighing from 8 to 10 Kgs each.

QUALITY :

AEPL has implemented a quality system for Copper Based Alloys where all processes are monitored from start to finish i.e. from procurement of raw material, their combination, manufacturing processes, measurement and chemical analysis. We maintain our own laboratory with calibrated equipments to ensure delivery of certified ingots as per International Standards and satisfy clients' requirements. The equipment includes Optical Emission Spectrometer which uses arc and spark excitation technology. Samples of test reports are available upon request.

VALUE ADDED SERVICES :

AEPL manufactures and supplies Copper Alloys products to Domestic as well as International Markets. Located at a single site, our smaller foundries are equipped to use in-house certified ingots and create complex shapes of Copper alloy castings and turn them into finished components using Drilling, Grinding and CNC turning centres.

COMPARATIVE SPECIFICATIONS :

CDA: C65100	ASTM: B98, B98M

FABRICATION PROPERTIES :

soldering	brazing	machinability rating
EXCELLENT	EXCELLENT	30

TYPICAL USES :

product category	product	reason
ELECTRICAL:	Conduit, Motor, Rotor Bars, Pole Line Hardware.	Electrical Conductivity, Thermal Conductivity, Corrosion Resistance, High Strength, Solderability, Brazability, Moderate Strength.
FASTENERS:	Bolts, Cable Clamps, Cap Screws, Fasteners, Machine Screws, Nuts, Rivets, Screws, U Bolts.	Corrosion Resistance, Corrosion Resistance to Fresh Water, Corrosion Resistance to Salt Water, High Strength, Excellent Formability, Electrical Conductivity, Formability.
INDUSTRIAL:	Heat Exchanger Tube, Hydraulic Pressure Lines, Oil Refinery Plumbing Tube, Welding Rod.	Corrosion Resistance, Corrosion Resistance to Fresh Water, Corrosion Resistance to Salt Water, Excellent Formability, High Strength, Weldability, Excellent Formability, Resistance to Stress Relaxation, Corrosion Resistance to Petrochemicals, Moderate Strength, Electrical Conductivity, Thermal Conductivity, Oxidation Resistance, Resistance to Thermal Softening.
MARINE:	Hardware.	Corrosion Resistance, Corrosion Resistance to Fresh Water, Corrosion Resistance to Salt Water, High Strength.
