Leaded Tin Bronze or High Leaded Tin Bronze are less expensive when compared to other bearing alloys. Primary function of this alloy is to improve machinability. Leaded Bronzes are well known for their resistance towards Corrosion and abrasion. The higher lead content allows the alloy to retain favourable thermal conductivity and good lubricity.
C93200 is considered as the general purpose bearing alloy in Leaded Tin Bronze family. It has excellent machining properties, improved hardness, strength and wear resistance with excellent antifriction qualities. C93200 Alloy is not subject to dezincification. C93200 is considered as the workhorse alloy in this family finding its applications in Bushing, Bearings and Automotive fittings.
| ELEMENT | Copper | Aluminium | Iron | Nickel | Zinc | Lead | Tin | Silicon | Sulphur | Antimony | Phosphorus |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Min (%) | 81.00 | - | - | - | 2.00 | 6.00 | 6.30 | - | - | - | - |
| Max (%) | 85.00 | 0.005 | 0.20 | 1.00 | 4.00 | 8.00 | 7.50 | 0.005 | 0.08 | 0.35 | 1.50 |
Note: Ni includes Co; Cu+ named elements >= 99.5%; Unless otherwise noted, single values represent maximums.
AEPL produces C92200, C92300, C92400, C92500, C92600, C92700, C92900, C93100, C93400, C93500, C93600, C93700, C93800, C93900, C94000, C94400, C94500, CC490K, CC495K, CC498K, CC499K, CuPb10Sn, CuPb10Sn10, CuSn10Pb10, CuSn10Pb5, CuSn7Pb6Zn3, LB-2, LBC-3, LBC-4, LTB-4, LTB-5, Leaded Tin Bronze alloy in the form of Certified Ingots weighing from 8 to 10 Kgs each.
AEPL has implemented a quality system for Copper Based Alloys where all processes are monitored from start to finish i.e. from procurement of raw material, their combination, manufacturing processes, measurement and chemical analysis. We maintain our own laboratory with calibrated equipments to ensure delivery of certified ingots as per International Standards and satisfy clients' requirements. The equipment includes Optical Emission Spectrometer which uses arc and spark excitation technology. Samples of test reports are available upon request.
AEPL manufactures and supplies Copper Alloys products to Domestic as well as International Markets. Located at a single site, our smaller foundries are equipped to use in-house certified ingots and create complex shapes of Copper alloy castings and turn them into finished components using Drilling, Grinding and CNC turning centres.
| CDA: C93200 | CuSn7Pb6Zn3 | SAE: J461, J462 | OTHER: BEARING BRONZE |
|---|
| soldering | brazing | machinability rating |
|---|---|---|
| EXCELLENT | GOOD | 70 |
| Casting Attribute | Level |
|---|---|
| CASTING YIELD | HIGH |
| DROSSING | LOW |
| FLUIDITY | MEDIUM |
| GASSING | MEDIUM |
| product category | product | reason |
|---|---|---|
AUTOMOTIVE: |
Automotive Fittings. | Corrosion Resistance, Corrosion Resistance to Numerous Environments, Good Machinability, Relatively Low Strength. |
FASTENERS: |
Washers. | Corrosion Resistance, Corrosion Resistance to Numerous Environments, Good Machinability, Relatively Low Strength. |
INDUSTRIAL: |
Bearings, Bearings for Cranes, Bushings, Diesel Engine Wrist Pin Bushings, Fittings, Forging Press Toggle Lever Bearings, Fuel Pump Bushings, General Purpose Bushings, Hydraulic Press Main Lining, Insert Bearings, Linkage Bushings for Presses, Machine Parts, Machine Tool Bearings, Main Spindle Bearings, Pump Fixtures, Pump Impellers, Pumps, Roll Neck Bearings, Rolling Mill Bearings, Thrust Washers, Trunion Bearings, Water Pump Bushings. | Corrosion Resistance, Corrosion Resistance to Numerous Environments, Anti-Seizing Properties, Low Coefficient of Friction, Wear Resistance,Good Machinability , Relatively Low Strength, Pressure Tight, Thermal Conductivity, Corrosion Resistance to Brackish Water, Corrosion Resistance to Many Industrial Chemicals, Corrosion Resistance to Petroleum Products. |
